Product Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: AFK
Certification: CE
Model Number: UT
Payment & Shipping Terms
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: Inside PE transparent bag, outside carton
Supply Ability: 2000 Piece/Pieces per Week
Type: |
Fittings |
Material: |
SS316, SS304 |
Applicable Media: |
Nitrogen,hydrogen,oxygen,argon,ammonia, Helium, Hydrogen, Gas, Etc. |
Maximum Pressure: |
3000psig |
Connection: |
Double Ferrule, NPT Threaded, Welded, Tube, Hose Barb Etc. |
Size: |
1/4", 3/8", 1/2", 3/4", 1", 3mm, 4mm, 6mm, 8mm,10mm,12mm |
Shape: |
Straight Union, 90degree Elbow, Tee(3 Way), Cross(4 Way) |
Port: |
Shenzhen |
Type: |
Fittings |
Material: |
SS316, SS304 |
Applicable Media: |
Nitrogen,hydrogen,oxygen,argon,ammonia, Helium, Hydrogen, Gas, Etc. |
Maximum Pressure: |
3000psig |
Connection: |
Double Ferrule, NPT Threaded, Welded, Tube, Hose Barb Etc. |
Size: |
1/4", 3/8", 1/2", 3/4", 1", 3mm, 4mm, 6mm, 8mm,10mm,12mm |
Shape: |
Straight Union, 90degree Elbow, Tee(3 Way), Cross(4 Way) |
Port: |
Shenzhen |
project laboratory gas air pneumatic 3 way plactic hose connector
Shape Instruction:
Connection Instruction:
Feature:
| Metric | |||||||||
| Tube O.D | Catalog number | A | D | E | F | G | H | J | K |
| 3 | UT-3-0 | 22.3 | 12.9 | 2 | 12 | 10 | 15.7 | 31.5 | 44.7 |
| 4 | UT-4-0 | 25.4 | 13.7 | 3 | 12 | 12 | 18.8 | 37.6 | 50.8 |
| 6 | UT-6-0 | 27.0 | 15.3 | 5 | 12 | 14 | 19.6 | 39.1 | 53.9 |
| 8 | UT-8-0 | 29.9 | 16.2 | 6 | 14 | 17 | 22.4 | 44.7 | 59.7 |
| 10 | UT-10-0 | 31.5 | 17.2 | 8 | 17 | 19 | 23.9 | 47.8 | 63.0 |
| 12 | UT-12-0 | 36.0 | 22.8 | 10 | 22 | 22 | 25.9 | 51.8 | 72.0 |
| 14 | UT-14-0 | 38.8 | 24.4 | 10 | 24 | 27 | 28.7 | 57.4 | 77.6 |
| 15 | UT-15-0 | 38.8 | 24.4 | 11 | 24 | 27 | 28.7 | 57.4 | 77.6 |
| 16 | UT-16-0 | 38.8 | 24.4 | 12 | 24 | 27 | 28.7 | 57.4 | 77.6 |
| 18 | UT-18-0 | 38.8 | 24.4 | 14 | 27 | 30 | 29.7 | 59.4 | 79.5 |
| 20 | UT-20-0 | 44.6 | 26.0 | 16 | 30 | 32 | 34.5 | 69.1 | 89.3 |
| 22 | UT-22-0 | 44.6 | 26.0 | 18 | 30 | 32 | 34.5 | 69.1 | 89.3 |
| 25 | UT-25-0 | 49.1 | 31.3 | 21 | 35 | 38 | 36.8 | 73.7 | 98.3 |
| Fractional | |||||||||
| 1/16 | UT-005-0 | 17.8 | 8.6 | 1 | 12 | 10 | 14.0 | 28.0 | 35.6 |
| 1/8 | UT-01-0 | 22.4 | 12.7 | 2 | 12 | 10 | 15.8 | 31.4 | 44.8 |
| 3/16 | UT-015-0 | 25.4 | 13.7 | 3 | 12 | 12 | 19.6 | 39.1 | 50.8 |
| 1/4 | UT-02-0 | 27.0 | 15.2 | 5 | 12 | 14 | 22.4 | 44.8 | 54.0 |
| 3/8 | UT-03-0 | 30.5 | 16.8 | 8 | 17 | 19 | 23.1 | 46.2 | 61.0 |
| 1/2 | UT-04-0 | 36.0 | 22.8 | 10 | 22 | 22 | 26.0 | 52.0 | 72.0 |
| 5/8 | UT-05-0 | 38.9 | 24.4 | 12 | 24 | 27 | 28.7 | 57.4 | 77.8 |
| 3/4 | UT-06-0 | 40.0 | 26.0 | 15 | 27 | 30 | 29.7 | 59.4 | 80.0 |
| 1 | UT-08-0 | 49.0 | 31.2 | 21 | 35 | 38 | 36.8 | 73.6 | 98.0 |
Q1. What products can you provide?
My dear friend, if you wanna know more information about our products, kindly send me inquiry or email, we will reply you within 24 hours!
Please provide the following parameters in your inquiry as many as possible:
1. Shape: straight union, 90° elbow, T(3 way), cross(4 way)
2. Connection: NPT male threaded, NPT female threaded, ferrule, welded, tube
3. Material: SS316, SS304
4. Media: what fluid is used for? Gas,oil?
5. Actual working pressure
6. Quantity
Please describe what kind of fittings do you need, then we can send you the exact model and quotation. For example, 90 degree elbow, one end is NPT male thread, the other is double ferrule(directly connected to tube), hydrogen gas, 1500psi, 3000pcs.
