1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Name: 1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head
Brand: Shenzhen Wofly Technology Co., Ltd.
SKU: SF+PF
Price: 17.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: AFK

Certification: CE

Model Number: SF+PF

Payment & Shipping Terms

Minimum Order Quantity: 1~10

Price: Negotiable

Packaging Details: Expotrt Packing

Delivery Time: 1WEEK

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 5000PC

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Forged Reducing Stainless Steel Weld Fittings, 1000psi Stainless Steel Weld Fittings, Hexagon Head Forged Steel Pipe Fittings


Material:	Stainless Steel,316L,Stainless Steel 304 Or 316,Stainless Steel304 316L	Shape:	Reducing
Head Code:	Hexagon	Connection:	Male,Female
Technics:	Forged	Medium:	Gas
Name:	Stainless Steel Tube Fittings	Size:	1/4" , 1" , 1/8" , 1/2" , 3/4"

Material:	Stainless Steel,316L,Stainless Steel 304 Or 316,Stainless Steel304 316L
Shape:	Reducing
Head Code:	Hexagon
Connection:	Male,Female
Technics:	Forged
Medium:	Gas
Name:	Stainless Steel Tube Fittings
Size:	1/4" , 1" , 1/8" , 1/2" , 3/4"

Description

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head

Short Description:

Model No.: SF+PF

Size: 1/8″, 1/4″, 3/8″, 1/2″, 3/4″ 1″ PT

Working pressure: 1000psi

Material: ss304

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 0

Model SF

Socket-Female Thread

Part No.	Female Thread Size T(pt)	Dimensions (mm)
Part No.	Female Thread Size T(pt)	L	Damx.	d
21SF	1/8”	44.5	Φ25	Φ5
22SF	1/4”	50.0	Φ25	Φ7
23SF	3/8”	51.0	Φ25	Φ9
24SF	1/2”	54.5	Φ25	Φ9
44SF	1/2”	60.0	Φ35	Φ15
46SF	3/4”	60.0	Φ35	Φ15
48SF	1”	68.0	Φ35	Φ15
48SF	1”	68.0	Φ35	Φ15

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 1

Model PF

Plug-Female Thread

Part No.	Female Thread Size T(pt)	Dimensions (mm)
Part No.	Female Thread Size T(pt)	L	IDamx.	d
21PF	1/8″	33.0	H14	Φ7.5
22PF	1/4-	36,0	H17	Φ7.6
23PF	3/8″	37.0	H19	Φ7.5
24PF	1/2^-	40.0	H24	Φ7.5
44PF	1/2-	45.5	H24	Φ12
46PF	3/4″	46.0	H30	Φ12
48PF	1”	51.5	H38	Φ12

Prodcut Display

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 2

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 3

Corporate Style

Projcet

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 8

Installation items of pressure reducer

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 9

Installation items of pressure reducer

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 10

Gas supply installation project

1000psi Forged Reducing Stainless Steel Weld Fittings Hexagon Head 11

Gas supply installation project

The above is our company, the project, we are the gas Porter, we not only sell products, but also for customers to install services
