Product Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: AFK
Certification: CE
Model Number: 2W-160-15B
Payment & Shipping Terms
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: plastic box+export carton
Supply Ability: 300000 Perch/Perches per Week
Application: |
General |
Media: |
Water |
Material: |
Brass Or Stainless Steel 304 |
Warranty: |
1 Year |
Standard Or Nonstandard: |
Standard |
Port: |
Shenzhen |
Application: |
General |
Media: |
Water |
Material: |
Brass Or Stainless Steel 304 |
Warranty: |
1 Year |
Standard Or Nonstandard: |
Standard |
Port: |
Shenzhen |
Brass Normally Closed 1/2 12VDC Low Voltage Water Solenoid Gas Valve
*Model No. : 2W-160-15B
*Pipe Size: 1/2 inch
*Orifice size: 16mm
*Thread: G, NPT
* Media: Air water oil, the neutral gas liquid
* Function type:Normally closed
* Working pressure : (water, air):1~10kgf/cm2 (Oil):0~7kgf/cm2
* Body material: Stainless steel
* Voltage: AC110V/220V/AC24V/DC24V/DC12V (Allow) ±10%
* Material of seal: NBR
*2-way normally closed solenoid valve, closed when de-energizes,open when energized.
|
Pipe size |
3/8 |
1/2” |
3/4” |
1” |
1 1/4“ |
1 1/2” |
2” |
|
Orifce size |
16mm |
16mm |
20mm |
25mm |
32mm |
40mm |
50mm |
|
CV valve |
4.8 |
4.8 |
7.6 |
12 |
24 |
29 |
48 |
|
fuild |
Air, water, ol, the neutral gas,liquid |
||||||
|
Service voltage |
AC380V,AC220V,AC110V,AC24V,DC24V, (allow)±10% |
||||||
|
Operating |
Pilot operating |
Type |
Normally closed |
||||
|
Body Material |
stainless teel 304, brass |
viscosity |
(Below)20CST |
||||
|
Working pressure |
Water, air;0-10kgf/m2 ;oil:0-7kgf/m2 |
||||||
|
Material of seal |
Standard: below 80 °C fuild temperature use NBR below 120°C use EPDM below 150 °C use VITON |
||||||
