Product Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: AFK
Certification: CE
Model Number: 2W-160-15
Payment & Shipping Terms
Minimum Order Quantity: 10 - 99 Pieces
Price: Negotiable
Packaging Details: PP bag+ white box+export carton
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 Piece/Pieces per Week
Media: |
Water |
Structure: |
Shutoff |
Product Size: |
1/8, 1/4, 1/2, 3/4, 1-1/4, 1-1/2, 2 |
Type: |
Normally Closed |
Working Pressure: |
0-10bar |
Warranty: |
1 Year |
Media: |
Water |
Structure: |
Shutoff |
Product Size: |
1/8, 1/4, 1/2, 3/4, 1-1/4, 1-1/2, 2 |
Type: |
Normally Closed |
Working Pressure: |
0-10bar |
Warranty: |
1 Year |
Body-Brass,stainelss steel
Seal- VITON,EPDM,VITON
Amature tube-stainless steel 304
Plunger-stainless steel430F
Stop-stainless steel 430F
Springs-SS304
Shading rings- red copper
|
Model NO. |
2w-025-06 |
2w-025-08 |
2w-040-10 |
2w-160-10 |
2w-160-15 |
2w-200-20 |
2w-250-25 |
2w-320-32 |
2w-400-40 |
2w-500-50 |
|
Pipe size |
1/8” |
1/4” |
3/8” |
1/2” |
3/4” |
1” |
1 1/4“ |
1 1/2” |
2” |
|
|
Orifce size |
2.5mm |
4mm |
4mm |
16mm |
16mm |
20mm |
25mm |
32mm |
40mm |
50mm |
|
CV valve |
0.23 |
0.6 |
4.8 |
4.8 |
7.6 |
12 |
24 |
29 |
48 |
|
|
fuild |
Air, water, ol, the neutral gas,liquid |
|||||||||
|
Service voltage |
AC380V,AC220V,AC110V,AC24V,DC24V, (allow)±10% |
|||||||||
|
Operating |
Direct acting |
Type |
Normally closed |
|||||||
|
Body Material |
Brass |
viscosity |
(Below)20CST |
|||||||
|
Working pressure |
Water, air;0-10kgf/m2 ;oil:0-7kgf/m2 |
|||||||||
|
Material of seal |
Standard: below 80 °C fuild temperature use NBR below 120°C use EPDM below 150 °C use VITON |
|||||||||
