Product Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: AFK
Model Number: 100D
Payment & Shipping Terms
Minimum Order Quantity: >=1 Sets
Price: Negotiable
Packaging Details: White box + Export packing
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 Set/Sets per Week
Power: |
Solenoid |
Media: |
Water |
Structure: |
Pilot |
Applicable Medium: |
Water |
Body Material: |
Nylon |
Type: |
Normally Closed |
Temperature: |
Suitable Water≤42℃, Surroundings≤52℃ |
Power: |
Solenoid |
Media: |
Water |
Structure: |
Pilot |
Applicable Medium: |
Water |
Body Material: |
Nylon |
Type: |
Normally Closed |
Temperature: |
Suitable Water≤42℃, Surroundings≤52℃ |
Medium:Water
Temperature: Suitable water≤42℃, surroundings≤52℃
Application range: It is currently one of the most widely used electromagnetic valve in garden irrigation, large-scale garden lawn, stadium, farm, industrial dust and water treatment equipment.
Model: 100D
Pressure: 0.1~1.0Mpa
Connect size: 1"
Thread: G
Orifice size: 25mm
Coil: AC220, AC110V, AC24V, 50/60HZ, 10VA
Self-holding type coil: DC6-20V, Pulse Width (20-500mSec)
Working model(+red&-black valve open)
(-red&-black valve closed)
Material-body valve -nylon enclosed-NBR
Moving iron core-430F
Static iron core-430F
Sping-SUS304 Sub-magnetic ring-Copper
Water treatment solenoid, normally closed, coil AC24V, Self-holding type coil DC6-20V (Please specify when ordering)
|
DESIGN FEATURES
|
|
|
1. Irrigation solenoid valve
|
|
|
2. Fit for stadium, farm, industrial dust and water treatment equipment.
|
|
|
3. Normally closed.
|
|
|
4.Pipe size 1".
|
|
|
5. Service voltage : DC latching/9VDC/12VDC/
24VDC/24VAC/110VAC/220VAC
|
|
|
6.Thread connection :G
|
|
|
7.Material-body valve -nylon
|
