Product Details
Place of Origin: China
Brand Name: AFK
Certification: CE
Model Number: 200P
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Expotrt Packing
Delivery Time: 1WEEK
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000PC
Material: |
Plastic |
Power: |
Solenoid |
Port Size: |
2",3/4",1",1/2",DC3~6V DC12V DC24V |
Temperature Of Media: |
Normal Temperature,Medium Temperature |
Media: |
Water |
Application: |
General |
Standard Or Nonstandard: |
Standard |
Voltage: |
24V. AC24V |
Working Pressure: |
Max1.6MPa |
Certification: |
CE |
Material: |
Plastic |
Power: |
Solenoid |
Port Size: |
2",3/4",1",1/2",DC3~6V DC12V DC24V |
Temperature Of Media: |
Normal Temperature,Medium Temperature |
Media: |
Water |
Application: |
General |
Standard Or Nonstandard: |
Standard |
Voltage: |
24V. AC24V |
Working Pressure: |
Max1.6MPa |
Certification: |
CE |
| No. | ITEM | TECHNICAL PARAMETERS |
| 1 | Material | nylon plastic body, NBR seal |
| 2 | Fluid | water |
| 3 | Fluid temperature | ≤43°C |
| 4 | Environment temperature | ≤52°C |
| 5 | Service voltage | 6-20VDC(can be order latching type coil), 24VAC, 24VDC, 110VAC, 220VAC |
| 6 | Pulse width | 20-500mSec (only for latching type) |
| 7 | Coil resistance | 6 Ω |
| 8 | Capacitance | 4700uF |
| 9 | Coil inductance | 12mH |
| 10 | Connection | G(BSP) female thread is regular, special order for NPT(3/4" and 1") |
