6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT

6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT
6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT

Large Image :  6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT

Product Details:
Place of Origin: China
Brand Name: AFK
Certification: CE
Model Number: NV33
Payment & Shipping Terms:
Minimum Order Quantity: 1~10
Price: Negotiable
Packaging Details: Expotrt Packing
Delivery Time: 1WEEK
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000PC

6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT

Description
Material: Stainless Steel,SS304 Port Size: 1/8" 1/4" 3/8" 1/2"
Pressure: High Pressure Temperature Of Media: High Temperature
Standard Or Nonstandard: Standard Media: Gas
Size: 3/4",1/4" NPT Valve Type: 2 Way
High Light:

Double Ferrule High Pressure Needle Valve

,

6000psi High Pressure Needle Valve

,

1/4" NPT Stainless Steel Needle Valve

FEATURES

  • Square bar stock body
  • Body material in Stainless Steel SS316/316L
  • Max.working pressure to 6000psi(413 bar) at 37℃(100℉)
  • TFM1600 packing as standard; Graphite packing for option
  • 100% factory tesred



TEST

Each AFK series needle valve is factory tested with nitrogen at 1000 psig(69 bar).



PRESSURE RATINGS OF VALVES WITH JPE COMPRESSION END CONNECTION ARE DETERMINED BY THE TUBING MATERIAL AND WALL THICKNESS.FOR MORE INFORMATION, PLEASE SEE AFK TUBE RTTING CATALOG.



6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 0

6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 1



PACKING MATERIALS & PRESSURE TEMPERATURE RATINGS

Body Material SS316/316L
Packing Material TFM1600 GRAPHITE
Temperature.C ("F) Working Pressure psig(bar)
-53°C 6000(413) 6000(413)
93(200) 5160(355) 5160(355)
121(250) 4910(338) 4910(338)
148(300) 4660(321) 4660(321)
176(350) 4470(307) 4470(307)
204(400) 4280(294) 4280(294)
232(450)   4130(284)
260(500)   3980(274)
315(600)   3760(259)
371(700)   3600(248)
426(800)   3460(238)
482(900)   3280(225)
537(1000)   3030(208)



  Packing Material  Body Material Temperature Rating
Stan Xrd  TFM1600 SS316/316L -53°C (-65°F) ~ +210°C(410°F)
Optional  GRAPHITE SS316/316L  -53*C (-65*F)~ +537*C(1000°F)



6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 2

ORDERING INFORMATION

C NV 33- S6- 02 A T D4
CL ASSIFI-CA PRODUCT NAME  VALVE TYPE  MATERIAL SIZE
(FRACTIONAL)

SIZE

(MRTRIC)

CONNECTION TYPE PACKING ORIFICE
C :VALVE NV :NEEDLE VALVE 1 :FORGED  S6 :SS316 02 :1/8* 4:4mm A:AFK TUBE END PACKING D4:4mm
      S6 L:SS316L  04 :1/4" 6:6mm MR :MALE BSPT THREAD PACKING D6:6mm
        06 :3/8* 8:8mm FR :FEMALE BSPT THREAD   D8:8mm
        08 :1/2" 10 :10mm MN :MALE NPT THREAD   D10:10mm
          12 :12mm FN :FEMALE NPT THREAD   D12:12mm
          14:14mm BW:BUTT WELD   D15:15mm
          15:15mm SW:SOCKET WELD
          16: 16mm UW:UNION WELD
          18:18mm
          20:20mm
          22:22mm
          25:25mm
          28:28mm
          32:2mm
          34:34mm



6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 3

6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 4

6000psi SS304 Double Ferrule High Pressure Needle Valve 1/4" NPT 5
