Product Details
Place of Origin: China
Brand Name: AFK
Certification: CE
Model Number: 075D 100D
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Expotrt Packing
Delivery Time: 1WEEK
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000PC
Application: |
General |
Power: |
Solenoid |
Temperature Of Media: |
Medium Temperature |
Flow Media: |
Water |
Port Size: |
3/4", 1" |
Structure: |
Shutoff |
Standard Or Nonstandard: |
Standard |
Material: |
Platic |
Pressure Environment: |
10 Bar |
Standard: |
AC220V, AC110V, AC380V, DC12V No Heating, DC24V No Heating |
Working Temperature: |
80 Degree |
End Connection: |
Thread |
Warranty: |
1 Year |
Application: |
General |
Power: |
Solenoid |
Temperature Of Media: |
Medium Temperature |
Flow Media: |
Water |
Port Size: |
3/4", 1" |
Structure: |
Shutoff |
Standard Or Nonstandard: |
Standard |
Material: |
Platic |
Pressure Environment: |
10 Bar |
Standard: |
AC220V, AC110V, AC380V, DC12V No Heating, DC24V No Heating |
Working Temperature: |
80 Degree |
End Connection: |
Thread |
Warranty: |
1 Year |
• Globe and angle configuration for flexibility in design and installation.
• Rugged PVC construction
• Filtered pilot flow to resist debris and clogging of solenoid ports.
• Slow closing to prevent water hammer and subsequent system damage.
• Manual internal bleed operates the valve without allowing water into the valve box.
• One-piece solenoid design with captured plunger and spring for easy servicing.
Prevents loss of parts during field service.
• Non-rising flow control handle adjusts water flows as needed.
• Normally closed, forward flow design.
| Model | 075D, 100D |
| Size | 3/4", 1" |
| end connection | thread G, BSP |
| working pressure | 0.1-1.04Mpa |
| low range | 1.14-70m³/h |
| water temperature | ≤43degree |
| environment temperature | ≤52degree |
| Material | plastic |
|
|
|
|
