Product Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: AFK
Certification: CE
Model Number: 2L-50
Payment & Shipping Terms
Minimum Order Quantity: >=1 Sets
Price: Negotiable
Packaging Details: White box + Export packing
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 Set/Sets per Week
Temperature Of Media: |
Medium Temperature |
Pressure: |
Low Pressure |
Power: |
Solenoid |
Media: |
Water |
Port Size: |
2" |
Applicable Medium: |
Liquid Gas Steam <20cst |
Temperature Of Media: |
Medium Temperature |
Pressure: |
Low Pressure |
Power: |
Solenoid |
Media: |
Water |
Port Size: |
2" |
Applicable Medium: |
Liquid Gas Steam <20cst |
| Maximum working pressure | 1.6Mpa |
| Operating pressure range | 0.2-1.6Mpa |
| Media temperature | <20cst liquid gas steam |
| Operation | Pilot type |
| Voltage | AC:380V 220V 36V/50Hz DC:24V |
| Isulation grade | B class |
| The power supply range | -15%~+10% |
| Power | 26W |
| Response time | open <=2 second close<=3 second |
| Install way | Media flow direction and the no the arrow consistent.The coil vertically upward, the working media clean and no particle impurities |
| Model | Thread | Size | Material |
| 2L-15 | G | 1/2" | Brass |
| 2L-20 | G | 3/4" | Brass Brass Brass Brass Brass |
| 2L-25 | G | 1" | |
| 2L-32 | G | 1 1/4" | |
| 2L-40 | G | 1 1/2" | |
| 2L-50 | G | 2" |
